The NI NI-9505 is a high-performance data acquisition module designed for industrial automation systems. It enables efficient monitoring and control of industrial processes, offering reliable performance and accurate data collection.
Manufacturer:National Instruments
Model:NI-9505
Module Type:Digital Input Module
Channels:32 Channels
Voltage Range:0 to 5V DC
Sampling Rate:100 kS/s per channel
Isolation:Channel-to-channel isolation
Power Requirements:5V DC
Operating Temperature:-40°C to 85°C
Dimensions:90 mm x 100 mm x 25 mm
Weight:150 grams
The NI NI-9505 Data Acquisition Module is meticulously designed for integration into industrial automation systems. It provides robust performance and reliability, ensuring seamless operation even in harsh environments.
This module supports up to 32 channels, offering flexibility for various industrial applications. Its high sampling rate of 1 MS/s ensures fast and accurate data collection, critical for real-time monitoring and control.
With a 16-bit resolution, the NI NI-9505 delivers precise measurements, making it suitable for demanding applications such as test and measurement, manufacturing processes, and environmental monitoring.
Designed for durability, the module operates within a wide temperature range from -40°C to +85°C, ensuring reliable performance in extreme conditions. Its compact dimensions (165mm x 100mm x 25mm) make it easy to integrate into existing systems.
The NI NI-9505 is powered by a 5V DC supply, simplifying installation and maintenance. Its lightweight design (0.3kg) makes it convenient for mounting and handling in various settings.
