Honeywell CC-TAOX11 Integrated System Module

CC-TAOX11

The Honeywell CC-TAOX11 is a redundant analog output module designed for use with the Honeywell Experion Process Knowledge System (PKS), specifically for the C300 controller family.

Function:
Analog Output: Provides multiple channels of analog output signals for controlling field devices such as valves, actuators, and positioners.
Redundancy: A redundant design with two independent output channels per point increases system availability and fault tolerance. Continuous operation is ensured even if one channel fails.
Output Types: Supports a variety of analog output formats, including
Voltage outputs (e.g. ±10V)
Current outputs (e.g., 0-20mA, 4-20mA).
Pulse Width Modulation (PWM) outputs for specialized control.
HART Communications: Some versions of the CC-TAOX11 also support HART (Highway Addressable Remote Transducer) communications, allowing digital communication with intelligent field devices for configuration, diagnostics, and additional process variables.

Main Specifications
Number of channels: Typically 16 output channels.
Resolution 12-bit resolution, analog signal that can be generated.
Output Ranges Various voltage and current ranges (e.g. ±10 V, 0-20 mA, 4-20 mA) can be configured.
PWM Output Frequency: 10 kHz high (if supported).
Resistive Load: 800 ohms high for current output (at 24V supply).
Output Current Linearity Typical ±0.05% of full scale nominal.
Calibration Accuracy Typical ±0.35% of full scale at 25°C (including linearity).
Operating temperature: -40 to +85°C (depending on model).
Dimensions approx. 229 mm (9.0 in) x 178 mm (7.0 in) x 44 mm (1.7 in).
Weight Approx. 2.2 kg (4.9 lbs).
Power: 24 VDC (nominal).

Integrated with Honeywell systems:
Experion PKS: The CC-TAOX11 is a key component of Experion PKS, Honeywell’s flagship distributed control system (DCS).
C300 Controller: The CC-TAOX11 is used in conjunction with the C300 controller, mounted on an Input/Output Terminal Assembly (IOTA).
I/O Link Interface: Connects to the C300 controller via an I/O link cable.
Configuration: Configuration and calibration via Experion PKS Control Builder software.

In summary, the Honeywell CC-TAOX11 is a highly reliable, redundant analog output module that is essential for controlling control elements in a variety of industrial automation applications within the Honeywell Experion PKS system. With redundancy, support for a variety of output types and HART communications, it is a versatile and reliable component for critical control loops.
