The GE IC697CPX928 is a high-performance CPU module designed for industrial automation systems.
It offers robust processing capabilities and reliable performance, making it ideal for complex control applications.
Brand:GE
Model:IC697CPX928
Series:PLC
Product Type:CPU Module
Dimensions:4.4 cm x 29.2 cm x 22.2 cm
Weight:0.5 kg
Voltage:220 V
Frequency:50 kHz
GE IC697CPX928 is the core processor module of GE Fanuc 90-70 series programmable logic controllers (PLCs), which is targeted at mid-end and high-end industrial automation control scenarios, especially for complex process monitoring and large-scale I/O systems.
Hardware Architecture Advantages
High-performance processor: 80486DX4 microprocessor with 96 MHz, supporting 32-bit floating-point operation and Boolean logic operation speed up to 0.4 μs/instruction, which is significantly higher than that of the same type of products in the same period of time (e.g., 0.5 μs/instruction on average for the Siemens SIMATIC S7-300 series).
Memory Configuration: 6 MB battery backup RAM ensures no data loss during power failure, and 256 KB non-volatile user flash memory is used for firmware storage and key program backup, which is better than the standard 2 MB configuration of Mitsubishi FX series.
Expandability: Supports up to 12K digital I/O and 8K analog I/O, far exceeding the 8K I/O capacity of the ABB AC500 series for large production lines.
Communication and protocol compatibility
Built-in communication ports: provides 1 RS232 and 2 RS485 serial ports, supports Modbus RTU/ASCII, Profibus and other protocols, and is compatible with Ethernet expansion modules (e.g., IC697CMM742), realizing multi-protocol parallel communication.
Industrial-grade protection: IP65 protection and -40°C~85°C operating temperature range, adaptable to harsh environments such as metallurgy and petroleum, and better than the IP20 standard of Schneider Modicon M340.
Software Ecology and Compatibility
Multi-Platform Programming Support: Compatible with MS-DOS and Windows programming software (such as LogicMaster 90), supporting ladder diagrams, structured text, and other programming languages to meet the needs of old system upgrades.
Modular Expansion: Programmable coprocessor, alphanumeric coprocessor and other optional modules can be connected to realize function customization, similar to the expansion capability of Siemens S7-400.
