The GE 369-HI-R-M-0-D-0-E is an advanced motor management relay designed to optimize motor performance and reduce downtime through real-time monitoring, event reporting, and waveform capture.
# of Digital/Switch Inputs:6 optically isolated
Ambient Humidity Maximum:Up to 95% non-condensing
Control Power nominal:20 VA
Control Power maximum:65 VA
Dimensions:approx. 11.5 in H x 5.5 in W x 8.5 in L
Fuse:3.15 A H 250 V
Maximum Altitude:2000 m (max)
Phase Current Inputs:1 A and 5 A secondary
Recordable Events:last 512 events
Communications:RS232 port, RS485 port
Waveform Capture Length:3 buffers containing 16 cycles of all current and voltage channels
Weight:approx. 10 lbs
The GE 369-HI-R-M-0-D-0-E Motor Management Relay is meticulously designed to monitor and manage industrial motors efficiently. With its advanced waveform capture technology, users can gain critical insights into motor performance and predict potential failures before they occur. The built-in event reporting and data logging functionalities further enhance the reliability and maintainability of your motor systems. The relay supports up to six digital or switch inputs, providing flexibility for various application scenarios. Designed to operate under harsh conditions, it is capable of handling ambient humidity up to 95% non-condensing and can function reliably at altitudes up to 2000 meters. This unit includes an optional metering package, which adds valuable metering capabilities, making it a comprehensive solution for motor management. The compact dimensions and lightweight design make installation straightforward and convenient, ideal for space-constrained environments. By integrating waveform capture, event reports, and data logging, the 369-HI-R-M-0-D-0-E significantly reduces maintenance costs and downtime, ensuring optimal motor operation and longevity.
