Allen Bradley 1746-NIO4V/A SLC500 Analog Combination Module

Model Type:SLC500

Model Number:1746-NIO4V

Manufacturer:Allen Bradley

Channels:2 Input, 2 Output

Input Range:-20 to 20 mA

Input Voltage Range:-20 to 20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Maximum)

Output Range:-10 to 10 V – 1 LSB

Full Scale Output:10 VDC

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Input Range Output:-10 to 10 VDC – 1 LSB

Current Rating:Backplane Current Draw: 55 mA

    Designed for precision control in industrial environments, the Allen Bradley 1746-NIO4V/A offers unparalleled accuracy and reliability.

    The module supports 2 input channels and 2 output channels, enabling efficient voltage and current monitoring and control.

    With a wide common mode voltage range and overvoltage protection, this module ensures stable operation even under challenging conditions.

    Its high resolution ensures precise measurement and control, making it ideal for applications requiring accurate data acquisition and process control.

    The Allen Bradley 1746-NIO4V/A is compatible with various Allen Bradley SLC500 systems, providing seamless integration into existing industrial automation setups.
